Radiocrafts MPC1 Series User Manual

Page 22 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Example 4 – Set desired TX_INTERVAL
Example
This example sets up the TX_INTERVAL to send an update every 1 hour:
1h = 60min*60s = 3600s.
TX_INTERVAL = 3600s/0.9s = 4000 ➔ 0x0FA0
Command
Hex
Response
Comment/Note
(Wake up)
0xFF
Wake up the UART interface
Enter
0x00
‘>’
Enter CONFIG mode.
Wait for ‘>’ prompt.
‘M’
0x4D
‘>’
M-command entered.
Wait for ‘>’ prompt.
0x2D
(none)
Address TX_INTERVAL_H (MSB)
0x0F
(none)
Value TX_INTERVAL_H (MSB)
0x2E
(none)
Address TX_INTERVAL_L (LSB)
0xA0
(none)
Value TX_INTERVAL_L (LSB)
0xFF
‘>’
Exit M-command.
Wait for ‘>’ prompt.
‘Z’
0x5A
(none)
Exit CONFIG mode.
Module returns to SLEEP state
