Radiocrafts MPC1 Series User Manual

Page 25 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Example 7 – Example message – Configuration message (OTA123, step 1), RC1180-MPC1
Example
The below shows the configuration dump message send from an RC1180-MPC1
module when OTA123 is enabled and the config pin is asserted.
L
C
LL_HEADER
APP DATA - NO TPL_HEAD
M_MID
M_MID
M_UID
M_UID
M_UID
M_UID
M_VER
M_DEV
CI
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
DATA
Field
Hex
Comment/Note
L
0x8A
Length
C
0x44
SND-NR
M_MID
0x24 0x48
Manufacturer ID. MSB first
M_UID
0x78 0x56 0x34 0x12
Unique ID. MSB first
M_VER
0x01
Version
M_DEV
0x00
General device
CI
0xAA
CI field for the Application Layer.
Short header.
DATA
01 05 03 01 02 00
09 00 FF 00 00 00 01 01
01 01 CC 00 00 01 00 00
17 00 00 48 24 12 34 56
78 01 00 00 00 00 00 00
00 00 00 00 03 03 7A 00
06 66 05 08 00 01 05 00
00 00 00 00 00 44 08 02
00 00 FF FF FF FF FF FF
FF FF FF FF FF FF FF FF
FF FF 00 00 00 00 00 00
00 00 00 00 00 00 00 00
00 00 00 52 43 31 31 38
30 2D 4D 50 43 31 2C 32
2E 30 30 2C 31 2E 30 30
20 00 00 00 00 00 00 00
00 00
Values for addr 0x00-0x05
Values for addr 0x07-0x0D
…
Note, the actual data record start after CI=AA (bold). There is no header in this message.
