Example 10 – Example message – Two pulse counters and flow for both
Example
You have set
• TX_INTERVAL to 2 hours
• MPC_FLOW1 = MPC_FLOW2 = 0x02
The message you receive can look like this:
L
C
LL_HEADER
APP DATA - SHORT TPL_HEAD
M_MID
M_MID
M_UID
M_UID
M_UID
M_UID
M_VER
M_DEV
CI
AN
SB
CW
CW
DIF
VIF
DATA
DATA
DATA
DATA
DIF
VIF
DATA
DATA
DATA
DATA
Field
Hex
Comment/Note
L
0x26
Length
C
0x44
SND-NR
M_MID
0x24 0x48
Master Manufacturer ID. MSB first
M_UID
0xAB 0xEF 0xCD 0xAB
Master Unique ID. MSB first
VER
0x01
Master Version
DEV
0x03
Gas meter
CI
0x7A
CI field for the Application Layer.
Short header.
AN
0x01
Access Number. Can be any number.
SB
0x00
Status Byte
CW
0x00 0x00
Configuration Word
DATA
0x0C 0x6E
0x00 0x01 0x00 0x00
BCD encoded, LSB first.
Counter 1 value = 100L.
DATA
0x0C 0x6F
0x50 0x00 0x00 0x00
BCD encoded, LSB first.
Flow for counter 1 = 50L/h.
DATA
0x0C 0x6E
0x00 0x01 0x00 0x00
BCD encoded, LSB first.
Counter 2 value = 99L.
DATA
0x0C 0x6F
0x50 0x00 0x00 0x00
BCD encoded, LSB first.
Flow for counter 2 = 49L/h.
