Radiocrafts MPC1 Series User Manual

Page 23 of 29
©2019 Radiocrafts AS
RC1180-MPC1/RC1701HP-MPC1 User Manual (rev. 1.1)
RC1180-MPC1
USER MANUAL RC1701HP-MPC1
Example 5 – Example message – SND-NR sent from dual electricity meter
Example
The below shows a message from a dual electricity meter
• Device Type = 0x02
• Counter 1 = 00001234
• Counter 2= 00002014
• Encryption off
L
C
LL_HEADER
APP DATA - SHORT TPL_HEAD
M_MID
M_MID
M_UID
M_UID
M_UID
M_UID
M_VER
M_DEV
CI
AN
SB
CW
CW
DIF
VIF
DATA
DATA
DATA
DATA
DIF
VIF
DATA
DATA
DATA
DATA
Field
Hex
Comment/Note
L
0x1A
Length
C
0x44
SND-NR
M_MID
0x24 0x48
Manufacturer ID. MSB first
M_UID
0x78 0x56 0x34 0x12
Unique ID. MSB first
M_VER
0x01
Version
M_DEV
0x02
Electricity meter
CI
0x7A
CI field for the Application Layer. Short header.
AN
0x00
Access Number. Increased by 1 for each
transmission
SB
0x00
Status Byte
If the battery voltage was below alarm threshold,
SB[2] will be set (0x04)
CW
0x00 0x00
Configuration Word
DIF
0x0C
User data DIF field
VIF
0x03
User data VIF field
DATA
0x34
User data LSB
DATA
0x12
User data
DATA
0x00
User data
DATA
0x00
User data MSB
DIF
0x0C
User data DIF field
VIF
0x03
User data VIF field
DATA
0x14
User data LSB
DATA
0x20
User data
DATA
0x00
User data
DATA
0x00
User data MSB
