15
Finalizing the pairing process
Once both devices are ready to pair press the key on the transmitter
and key on the receiver. You must press these keys within a
30 second window, otherwise the connection may time out.
The transmitter and the receiver will now attempt to pair.
When pairing is in progress, the transmitter and receiver will display a ashing Bluetooth
®
icon. Pairing can take up to a minute. If the pairing process is successful, the transmitter
will display the icon and the receiver will display a persistent Bluetooth
®
icon for the
duration of the connection.
If pairing fails, ensure that any nearby Bluetooth
®
devices are switched off
or invisible then repeat the process.
Once the receiver and transmitter have successfully paired you can use iLOC™ to
change the transmitter’s output frequency and power levels remotely with the receiver.
Using iLOC
Changing transmitter frequency
Switch on the receiver and transmitter by pressing the key on their
respective keypads.
Pair the receiver and the transmitter if you have not already done so.
On the receiver, select the frequency you want by pressing the key until the
frequency is displayed on screen.
iLOC commands are sent using the key, press it to send the new frequency
to the transmitter.
The receiver’s LCD will display OK on success or FAIL if the iLOC command
was unsuccessful.
Changing transmitter power output
Pair the receiver and the transmitter if you have not already done so.
Transmitter power options are located in the TXOUT menu on the receiver.
Press and hold the key to display the TXOUT menu.
Press the key to enter the TXOUT menu.
Scroll through the power output options using the or keys; available
options are:
STDBY: Transmitter standby mode, the connection is still active but the
output is disabled.
LOW: low power output.
MED: medium power output.
HIGH: high power output.
1.
2.
1.
2.
3.
4.
5.
1.
2.
3.
4.
•
•
•
•
