ENGLISHDEUTSCHESpAñoLFRANÇAISITALIANoNEDERLANDS
7
Receiver features
Keypad.
LCD.
Battery compartment.
Accessory slot.
Headphone jack.
Receiver keypad
Power key : Switches the unit
on and off. Opens the receiver
menu.
Frequency key : Selects
frequency. Closes submenu.
Up and down arrows
Adjusts the signal gain. Scrolls
through the menu options.
Antenna key : Toggles peak,
null, single antenna and combined
peak/null modes. Opens a
submenu. Prolonged key press
toggles between depth or current
display on the LCD.
Graph key : Saves
SurveyCERT™ measurements.
Transmitter key : Sends iLOC™
commands on iLOC™ enabled
receivers to iLOC™ enabled
transmitters.
Receiver screen icons
Indicates the signal strength and
peak marker.
Signal strength: Numerical
indication of signal strength.
Peak / Proportional arrows:
Indicates the location of the line
relative to the receiver.
Battery icon: Indicates the battery
level.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Sensitivity and Log number:
Displays the log number
momentarily after a survey log is
saved to memory.
Volume icon: Displays the volume
level.
Current Direction arrows.
Radio Mode: Indicates when
Radio Mode is active.
Power Mode: Indicates when
Power Mode is active.
Accessory indicator: Indicates
when an accessory is connected.
CD Mode icon: Indicates when
Current Direction Mode is active.
A-Frame icon: Indicates when the
A-Frame is connected.
Operating mode indicator.
Bluetooth
®
icon: Indicates status
of Bluetooth
®
connection. Flashing
icon means pairing is in progress.
Solid icon indicates an established
connection is active.
Antenna mode icon: Indicates
antenna selection: Peak, Null,
single and combined Peak/Null.
Sonde icon: Indicates that the
signal source is from a sonde.
Line icon: Indicates that the signal
source is from a line.
Compass: Shows the direction of
the located cable relative to the
receiver.
Tx status: Displays transmitter
connection status.
Tx standby: Indicates that the
transmitter is in Standby Mode.
Current / depth indicator.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
