Transmitter features
Keypad.
LCD.
Removable accessory tray.
Transmitter keypad
Power key : Switches the unit
on and off. Opens the transmitter
menu.
Frequency key : Selects
frequency. Menu navigation key.
Up and down arrows
:
Adjusts the output signal. Scrolls
through the menu options.
Measure key : Toggles
measurement display between
volts, current and impedance.
Note: displayed measurements are
based on the currently selected
mode or the attached accessory, if
applicable. Opens a submenu.
Transmitter screen icons
Battery icon: Indicates the battery
level.
Alphanumeric description of
selected operation mode.
Standby icon: Appears when the
transmitter is in Standby Mode.
Output level: Displays transmitter
output power.
Clamp icon: Indicates when a
clamp or other plug is connected.
DC icon: Appears when the
transmitter is powered from a DC
source.
Induction indicator: Appears when
the transmitter is in Induction
Mode.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
A-Frame (Tx3 and Tx10 only):
Indicates when the transmitter is in
Fault-Find Mode.
CD Mode indicator (Tx10 only):
Indicates that the transmitter is in
Current Direction Mode.
Voltage warning indicator:
Indicates that the transmitter is
outputting potentially hazardous
voltage levels.
Volume icon: Displays the
volume level.
Pairing icon (Tx3B and Tx10B
only): Appears when the
transmitter and receiver are
connected via iLOC™.
Bluetooth
®
icon (Tx3B and
Tx10B only). Indicates status of
Bluetooth
®
connection Flashing
icon means pairing is in progress.
15.
16.
17.
18.
19.
20.
