D7112 and D9112B Messages Transmitted in BFSK
Automation Output
Signal D6500 Internal/External Printer D6500 Mode SIA Mode Notes
D9112B/D7112 Fire Messages – BFSK
Fire Alarm dd/dd tt:tt ql ACCT aaa FIRE FR z h1rrlssssssaaaasFssszt <header>[#aaaa|
NFAz
] 2, 3, 9
Fire Trouble dd/dd tt:tt ql ACCT aaa TROUBLE FR z h1rrlssssssaaaaGsssszt <header>[#aaaa|
NFTz
] 2, 3, 9
Fire Missing dd/dd tt:tt ql ACCT aaa TROUBLE FR z h1rrlssssssaaaaGsssszt <header>[#aaaa|
NFTz
] 2, 3, 9
Fire Restoral dd/dd tt:tt ql ACCT aaa RESTORAL FR z h1rrlssssssaaaaHsssszt <header>[#aaaa|
NFRz
] 2, 3, 9
after Alarm
Fire Restore dd/dd tt:tt ql ACCT aaa RESTORAL FR z h1rrlssssssaaaaHsssszt <header>[#aaaa|
NFRz
] 2, 3, 9
after Trouble/Missing
Fire Walk Start dd/dd tt:tt ql ACCT aaa TROUBLE ZN F h1rrlssssssaaaasTsssFt <header>[#aaaa|
NBTF
]
D9112
Fire Walk End dd/dd tt:tt ql ACCT aaa RESTORAL ZN F h1rrlssssssaaaasRsssFt <header>[#aaaa|
NURF
]
D9112
D9112B/D7112 Alarm Messages – BFSK
Alarm dd/dd tt:tt ql ACCT aaa ALARM ZN z h1rrlssssssaaaasAssszt <header>[#aaaa|
NBAz
] 2, 9
Duress dd/dd tt:tt ql ACCT aaa ALARM ZN z h1rrlssssssaaaasAssszt <header>[#aaaa|
NBAz
] 2. D7112: z=0.
D9112: z= as programmed in
BFSK Duress Code
User Alarm 7 dd/dd tt:tt ql ACCT aaa ALARM ZN z h1rrlssssssaaaasAssszt <header>[#aaaa|
NBAz
] 2. D7112: z=7
D9112: z= as programmed for point (
Point Code Digit One
=4)
User Alarm 9 dd/dd tt:tt ql ACCT aaa ALARM ZN z h1rrlssssssaaaasAssszt <header>[#aaaa|
NBAz
] 2. D7112: z=9
D9112: z= as programmed for point (
Point Code Digit One
=5)
Cancel Alarm by Area dd/dd tt:tt ql ACCT aaa CANCEL REPORTh1rrlssssssaaaas\sssst <header>[#aaaa|
NOC
] 2, 9
Trouble dd/dd tt:tt ql ACCT aaa TROUBLE ZN z h1rrlssssssaaaasTssszt <header>[#aaaa|
NBTz
] 2, 9
Restoral dd/dd tt:tt ql ACCT aaa RESTORAL ZN z h1rrlssssssaaaasRssszt <header>[#aaaa|
NURz
] 2, 9
Missing Alarm dd/dd tt:tt ql ACCT aaa ALARM ZN z h1rrlssssssaaaasAssszt <header>[#aaaa|
NBAz
] 2, 9
