Radionics D6500 - Ademco 4-1 Express; Ademco 4-2 Express

D6500 Computer Interface Manual
74-05313-000-G 10/16/97 Page 63 © 1988-1997 Radionics, Inc.
Definition of automation output codes:
h: Header
8: Ademco High Speed protocol identifier
rr: Receiver number
l: Line Card number
s: Space
aaaa: Account code
C: Channels 1-8
S: Supervisory channel
t: Trailer
Ademco 4-1 Express
Receiver sends to computer:
D6500 Mode: hbrrlssssssaaaasEsssXt
SIA Mode: <LF><CRC>b<seq><rec><line>[#aaaa|X]<CR>
Receiver sends to printer:
mm/ddshh:mmsE41sLxxsACCTsaaaassssEVENT=X
E41: Ademco 4-1 Express format
Lxx: Line number
Definition of automation output codes:
h: Header
b: Ademco 4-1 Express protocol identifier
rr: Receiver number
l: Line Card number
s: Space
aaaa: Account code
X: Event code, 'A' as factory default
t: Trailer
Ademco 4-2 Express:
Receiver sends to computer:
D6500 Mode: hcrrlssssssaaaasEssXYt
SIA Mode: <LF><CRC>c<seq><rec><line>[#aaaa|XY]<CR>
Receiver sends to printer:
mm/ddshh:mmsE42sLxxsACCTsaaaasssEVENT=XY
E42: Ademco 4-2 Epress format
Lxx: Line number
Definition of automation output codes:
h: Header
c: Ademco 4-2 Express protocol identifier
rr: Receiver number
l: Line Card number
s: Space
aaaa: Account code
E: Event code, 'A' as factory default
XY: Event number and zone number
t: Trailer
