D6500 Computer Interface Manual
74-05313-000-G 10/16/97 Page 4 © 1988-1997 Radionics, Inc.
Line Card Groups and Supervision Parameters
Line Card 1
(Line Card Options) program as needed for Rotary Hunt Groups and through
Supervision.
Line Card 8
Internal Printer Parameters
Device
(Internal Printer Select), usually set to
Primary
or
Secondary
. Other options include
Always On
and
Always Off
.
NOTE:
Supervision
operates independently from
Device
.
Supervision
(Internal Printer Supervision) should be
Yes
. If the printer is not supervised by the
receiver, there will be no indication at the computer if printer problems occur.
External Printer Parameters
Device
(External Printer Select), usually set to
Primary
or
Secondary
. Other options
include
Always On
and
Always Off
.
Supervision
(External Printer Supervision) should be
Yes
. If the printer is not supervised by the
receiver, there will be no indication at the computer, if printer problems occur.
XON/XOFF
(External Printer XON/XOFF) should be
Yes
to receive signals from the external
printer
CR/LF
(External Printer Carriage Return/Line Feed)
Yes
enables a carriage return line feed
between reports.
No
prints continuous reports.
Parity
(External Printer Parity)
Even
parity,
Odd
parity,
No
parity
Baud Rate
(External Printer Baud Rate)
110
,
300
,
600
,
1200
,
2400
.
Data Bits
(External Printer Bit Transmission Value)
Eight
bit data transmission or
Seven
bit
data transmission.
Automation Config Parameters
Output Format
(Computer Output Format) Enable computer output messages in the selected
format:
SIA
Computer Interface Standard format
6500
21 character format output
(expanded reporting capabilities)
Device
(Computer Select), usually set to
Primary
or
Secondary
. Other options include
Always On
and
Always Off
.
Supervision
(Computer Supervision) set to
Yes
if a computer is used.
