3.4 ASSEMBLING THE RECOIL HANDLE LOOP
(Optional) Fix the recoil handle connection cord with the recoil handle loop.
Bracket
Power
Lever
Brake Line
Connector
Braket Hole
Recoil
Handle
Recoil
Handle Loop
Grass Bag
Rear Discharge
Cover
Recoil
Handle
Recoil
Handle Loop
