RADWAG AS 220.R User Manual

- 150 -
Procedure:
− press button
− enter menu <P4 DEVICES>
− and then enter in menu group<P4.4 ADDITIONAL DISP.>
− set the balance parameters related to the cooperation with the
additional display
<P4.4.1 PORT> - choice of the port, to which the additional display
is to be connected
o accessible options: none, COM 1, COM 2
CAUTION:
The balance cooperates with an additional display manufactured by
RADWAG.
Ensuring correct cooperation between the balance and the additional
display requires that the parameter of the baud rate value set to 115200
bit/s for the port to which the additional display is plugged.
19.5. External buttons
Submenu <EXTERNAL BUTTONS> contains the settings that enable the
balance to cooperate with external buttons: TARE and PRINT.
The procedure is following:
• Press
•
Enter menu <P4 DEVICES>
•
Enter in the menu group <P4.5 EXTERNAL BUTTONS>
•
Activate the buttons
<P4.5.1. TARE> for <YES>
<P4.5.2. PRINT> for <YES>
• Exit the balance manu
CAUTION:
The balance program enables cooperation with one or both buttons. If you
need to connect both external buttons, connect a socket outlet adapter to
COM 2 port, and connect buttons TARE and PRINT to the adapter.
Connect the printer or terminal to COM 1 or to the socket outlet adapter
(determine the PRINTER-BALANCE transfer perametres). Every time you
