RADWAG R Series User Manual

- 79 -
CAUTION! CODES MUST BE ENTERED IN A HEXADECIMAL FORM!
Example balance settings for correct cooperation with TM-U220B EPSON matrix printer connected to
RS232 port (since this printer features only 852 code page, there won’t be any Polish signs on
a printout):
Communication parameters for port to which the printer is connected:
• BAUD RATE - 9600 bit-s
• PARITY – none
Printer parameters for a PERIPHERALS group:
• PORT – COM1 or COM2 (the one to which the printer is connected)
• PREFIX - 1B742D (1250 code page)
• SUFFIX - 1D564108 (paper crop for EPSON printers equipped with an autocutter blade)
Example balance settings for correct cooperation (printout of Polish signs) with TM-T20 EPSON
thermal printer connected to RS232 port; if the printer is connected to USB port than the baud rate
settings and parity do not matter.
Communication parameters of port to which the printer is connected:
• BAUD RATE - 38400 bit-s
• PARITY – none
Printer parameters for a PERIPHERALS group:
• PORT – COM1 or COM2 (the one to which the printer is connected)
• PREFIX - 1B742D (1250 code page)
• SUFFIX - 1D564108 (paper crop for EPSON printers equipped with an autocutter blade)
If on the printout in the place of the last digit there are any unexpected signs (for verified balances),
than <P4.2.2 PREFIX> parameter should incorporate, apart from code page, enter code of the UK
signs chart: 1B5203. In such a case the <P4.2.2 PREFIX> parameter setting should be as follows:
• PREFIX - 1B742D1B5203 (1250 code page and UK signs chart)
Control codes for exemplary code pages:
Control code
Page or other command
1B742D code page 1250
1B7410 code page 1252
1B7430 code page 1254
1B5203 UK signs chart
1B5202 DE signs chart
1D564108 Paper crop
0C Form feed (for PCL printers)
13.3. BARCODE READER
Submenu <BARCODE READER> comprises settings for cooperation with a barcode reader.
Procedure:
• press button
• enter <P4 DEVICES> menu
• enter menu group <P4.3 BAR CODE READER>
• select port to which the barcode reader is to be connected: NONE, COM 1, COM 2
CAUTION! R series balances are compatible with RADWAG barcode scanners
