2 ESP-LX+ & LXi+ Installation, Programming, & Operation Guide
INTRODUCTION
LX+ and LXi+ Series Controllers
The ESP (Extra Simple Programming) -LX+, -LXi+ Series
controller is an irrigation timing system for residential and light
commercial use.
The ESP-LX+ comes in 6-, 8-, 12-, 16-, 20-, or 24-station
models, designed for either indoor or outdoor use. The
ESP-LXi+ comes in 8-, 12-, or 16-station models, for indoor use
only.
ESP-LX+ and ESP-LXi+ controllers bearing the
remote ready icon (shown at right) can be
connected to Rain Birds Radio Frequency (RF)
receivers (RM-1R & RMX-1R).
For example, the illustration on page 3 shows that station 1 is
currently watering. When station 1 is finished, the controller
will shut it off and start station 2. In the same way, station 3 will
begin watering when station 2 is finished.
NOTE: ESP-LX+ and -LXi+ controllers let you set a
delay between stations. For example, if you set a one-
minute delay, station 1 will run until finished, followed
by a one-minute delay. Then station 2 will operate,
followed by a one-minute delay.
Controller Stations
Your ESP-LX+ or LXi+ Series controller is an electronic clock
that controls when your sprinkler system turns on, and how
long the sprinklers run. The controller has several sprinkler
stations connected to it, as shown in the illustration on the
following page. Each station is connected to a remote control
sprinkler valve.
The valve opens when it receives power from the controller,
and the sprinklers connected to that valve turn on. When these
sprinklers have run for their programmed time, the controller
shuts off the valve and opens the next valve in sequence.
