13ESP-LX+ & LXi+ Installation, Programming, & Operation Guide
Programs A, B, and C are not allowed to overlap each other. If
they are programmed to overlap, programs A, B, or C will
stack (run in consecutive order upon the completion of the
program in progress).
Program stacking prevents excessive flow demand and low
water pressure caused by having too many valves running at
one time.
NOTE: It is easier to select one program and program
it completely. Jumping from program to program can
be confusing.
Select Program
Four independent programs are available in the ESP-LX+,
LXi+ Series controller: A, B, C, and D-drip. Multiple indepen-
dent programs let you enter watering schedules to meet the
requirements of different types of plant materials, soils, slopes,
shady or sunny areas, etc.
The D-drip program is designed for drip irrigation equipment.
Stations assigned to the D-drip program cannot be assigned
to any other program. The D-drip program can overlap, or run
concurrently, with programs A, B, or C.
➊ Turn the dial to AUTO.
➋ Press PGM to cycle through the available programs. The
program indicator on the far left side of the display shows
which program is currently selected.
