66 ESP-LX+ & LXi+ Installation, Programming, & Operation Guide
Display shows a station
operating, but no watering
occurs.
7. Sensor system is preventing irrigation.
(WATERING SUSPENDED BY SENSOR light is
on.)
Turn the sensor bypass switch to OFF. If watering
resumes, the sensor is operating properly, and no
correction is necessary.
8. No sensor or jumper is connected to the
controllers SENSOR terminals, and the
SENSOR BYPASS switch has been set to
ACTIVE.
Turn the sensor bypass switch to OFF. To prevent
future occurrences, install the supplied jumper on
the controllers SENSOR terminals. See page 54.
Station does not come on. 9. No run time has been set for the station. Turn the dial to the station number, and press the
PGM button to check the run times set for the
station. To add a run time, see page 19.
10. A short circuit in the solenoid or valve wiring
has disabled the station. (Display shows
FAULT and a station number, and the
FAULT light in the upper left corner of the face
panel is on.)
Identify and repair the fault in the circuit. Then press
the Clear Fault button, and start the station manually.
See page 35 for instructions.
11. Sensor system is preventing irrigation.
(WATERING SUSPENDED BY SENSOR light is
on.)
See correction for Cause #7.
12. Start time has not been entered for the
program to which the station is assigned.
See correction for Cause #2.
13. Water Budget for the stations program is set
to 0%.
See correction for Cause #6.
SYMPTOM POSSIBLE CAUSE SOLUTION
