ESP-LXD 2-Wire Decoder Control System Installation & Troubleshooting Guide
9
Rain Bird LIMR Controller Remote
ESP-LXD Control System Flow & Weather Sensors
Flow Sensors
Up to five (5) flow sensors can be installed on the 2-Wire path. SD-210 Sensor Decoder are required
for each sensor. Rain Bird FS-Series Flow Sensors are available in ½” to 4” PVC Tee, 1” to 2” Brass Tee,
and Brass and Stainless Steel Insert Style models.
Rain Bird FS-Series Flow Sensors
LIMR-KIT
900MHz Transmitter,
Receiver, Quick-Connects,
Carrying Case
LIMR-TX
900MHz Transmitter Only
LIMR-RX
900MHz Receiver Only
LIMR-QC603
6-Pin Quick Connect
Cable, 3 feet
LIMR-QC630
6-Pin Quick Connect
Cable, 30 feet
FS050P
½” Slip x Slip, PVC Tee
Flow Sensor
FS075P
¾” Slip x Slip, PVC Tee
Flow Sensor
FS100P
1” Slip x Slip, PVC Tee Flow
Sensor
FS150P
1-½” Slip x Slip, PVC Tee
Flow Sensor
FS200P
2” Slip x Slip, PVC Tee Flow
Sensor
FS300P
3” Slip x Slip, PVC Tee Flow
Sensor
FS400P
4” Slip x Slip, PVC Tee Flow
Sensor
FS100B
1” Threaded, Brass Tee
Flow Sensor
FS150B
1-½” Threaded, Brass Tee
Flow Sensor
FS200B
2” Threaded, Brass Tee
Flow Sensor
FS350B
Brass Insert (for Pipe
Saddle) Flow Sensor for 3”
to 12” Pipe Diameters
Pipe Inside Diameter
entry required
FS350SS
Stainless Steel Insert
(for Pipe Saddle) Flow
Sensor for 3” to 12” Pipe
Diameters
Pipe Inside Diameter
entry required
Custom
3rd-party flow sensor or
meter
K-Factor and Offset entry
required (supplied by
3rd-party manufacturer)
Reed-Switch 2-wire
output only with
minimum 2 pulses per 10
seconds for the lowest
station flow rate
