RainPoint ITV201P User Manual

PRODUCT OVERVIEW
At A GLANCE
DIAL
FILTER
HOSE TAP
CONNECTION
PBUTION
OK/MANUAL
BUTTON
ZONE
BUTTON
BIG LCD
SCREEN
DELAY/+
BUTTON
-BUTTON
ZONE L
ZONE R
+ /DELAY BUTTON
BUTTON FUNCTION
- BUTTON
P BUTTON
ZONE BUTTON
OK / MANUAL
BUTTON
Use "+" to adjust the time. When the dial is
turned to "ON", press and hold "DELAY" to
activate Rain Delay.
Use "-" to adjust the time.
Use "P" to switch watering plans P1, P2, P3
Switch between ZONE L and ZONE R
Use "OK" to conrm the time. When the dial is
turned to "ON", press and hold "MANUAL" to
water manually.
- 01 -
ENEN

RainPoint ITV201P Specifications

General

Brand	RainPoint
Model	ITV201P
Category	Timer
Language	English
