H. Dual-Extruder Print - Start First Print (continued)
Please use the feeler gauge to check the distance
between nozzle and printing platform. The optimal
distance between is 0.2mm.
The best condition of this is that you can feel a little
friction when you slide the feeler gauge into the gap.
5
0.2mm
Feeler Gage
The distance between the nozzle and the printing
platform can be adjusted by turning the thumb
screw on the left-front corner of the
Z-plate, the higher the screw stands, the further the
distance between the nozzle will be from the printing
platform.
Home the Z axis after each adjustment.
6
Closer Further
Once the left nozzle moves down, the right nozzle
will go up.
4
