Raisecom RC3000 PCM User Manual

Raisecom Technology Co., Ltd
13
RC3000-OPT-S1FC Single-mode Dual-fiber 1310,DFC, 0~25Km
RC3000-OPT-M Single-mode Dual-fiber 1310,DSC, 0~2Km
RC3000-OPT-AS1 Single-mode Dual-fiber 1310,DSC, with ALS function, 0~25Km
RC3000-OPT-AS2 Single-mode Dual-fiber 1310,DSC, with ALS function, 10~50Km
Note: device types in the shadow are customized products.
For power supply type (after the device type), voltage range of AC is 85 to 265V and DC
is -36 to -72 V
ALS: Automatic Leaser Shutdown/Reduction.
4.2. User-board type explanation:
Explanation of RC3000 user-board type:
RC3000-SUB- D XXX
User-boards of RC3000:
User-board type User-board name Channel description
RC3000-SUB-DS FXS user voice user-board 8 channels, unconfigurable
RC3000-SUB-DO FXO voice relay user-board 8 channels, unconfigurable
RC3000-SUB-DSO FXS and FXO hybrid voice
user-board
8 channels, unconfigurable
RC3000-SUB-DM2 E&M 2 audio relay user-board 8 channels, unconfigurable
RC3000-SUB-DM4 E&M 4 audio relay user-board 4 channels, unconfigurable
RC3000-SUB-DV35 V35 data user-board 1 interface, and the time
slots of channel is
configurable
RC3000-SUB-DV24 V24 data user-board 1 interface, and the time
slots of channel is
configurable
RC3000-SUB-DETH 10BaseT Ethernet data
user-board
1 interface, and the time
slots of channel is
configurable
RC3000-SUB-D232 RS232 serial data user-board 8 channels, unconfigurable
Device name: multi-service multiplexer
Identifier of user-board
Identifier of user-board type
Name of user-board
