0 and single E1 direction.
Device 5: Set all DIP-switches OFF; use one E1, time slot 0 and single E1 direction.
To avoid error the above configuration is recommended.
10.9.7. Alarm Sound Set
In system menu press number key 7 to configure the alarm sound:
Alarm Sound Output: Disable
In this status, press ENTER to confirm configuration (or press ENTER until the
configuration finished), press E key to finish configuration, and ESC to cancel
configuration.
By default the alarm sound output is ENABLE, when disable the sound there will not be
alarm sound.
10.9.8. User Board Set
In system menu press number key 8 to configure the user-board:
Input User Board No.(1-3, Esc=Cancel):
If the relative user-board does not exist, there will be the following information:
The First board is not exist.
System Set Command:1-9, Menu Display:M, Return:Q Command:
If the user-board exists, then you can configure.
When user-board types are: 1 (FXS user voice card), 2 (FXO voice relay card), 3 (FXS &
FXO hybrid card), 4 (EM2 audio relay card), 5 (EM4 audio relay card), and 11 (magneto
telephone care) the set menu will be:
1.Input Signal
2.Output Signal
3.Signal Bit
User-Board1(FXS Board) Set Command:1-3, Menu Display:M, Return:Q Command:
Note: the command explanation is available in 8.11 User Board Set (with signal)
menu.
When the user-board types are: 6 (V35 user-board), 7 (V24 user-board) the menu will
be:
1.Sub-Board Slot Number
2.Receive Datat Phase
3.Transmit Data Phase
4.Channel Select
5.Loopback Set
6.Error Code Test
7.Auto to Adjust Phase for Transmit
8.To Adjust Receive Phase
To Next Page
