COVER REMOVAL
30
R221/A - R221/A DHHS - Cover Removal
Ralco srl
GENTLY EASE THE TAPE INTO
THE COLLIMATOR.
REMOVE THE SCREW FROM
THE SNAP-FIT PLATE.
REMOVE THE PLATE AND
THEN LIFT THE COLLIMATOR
COVER OFF.
REMOVE THE COVER BY
LIFTING IT OFF THE
COLLIMATOR.
