MTR221/A - MTR221/A DHHS
MANUALE ISTRUZIONI / INSTRUCTION MANUAL
Modello/Model R221/A - R221/A DHHS
MAINTENANCE
55
R221/A - R221/A DHHS - Maintenance
Ralco srl
• Clean the collimator with a soft cloth paying particular attention to the plastic anti-dust
window. Do not use abrasive or inflammable cleaning products.
• Wipe away all excess oil and remount the cover.
MAKE SURE TO TIGHTEN THE ALLEN SCREWS SECURING THE COLLIMATOR OR THE
CONTROL TABS.
A
PPROPRIATE TIGHTENING OF THE 4 ALLEN SCREWS ENSURES SECURE MOUNTING
OF THE COLLIMATOR. TIGHTENING FORCE USED MUST NOT EXCEED 0.50 NM.
IF THE COLLIMATOR IS TO BE MOUNTED ON A ROTATING FLANGE, USE A TIGHTENING
FORCE BETWEEN MIN. 0,50 NM AND MAX. 0.75 NM.
