SECTION 4 - CARRIAGE.
Rev B – June 2013
Page 4-13
4.14
Turn gear reducer manually to raise the counter weight
from the hangers (FIG. 11), make sure that the counter
weight is not resting on the hangers before continuing with
the next step.
Figure 11. Removing the counter weight hangers and
bottom counter weight plate, and installation of a
lock nut on the threaded shaft. Looking from behind
the guide rails.
NOTE:
Parts may not be exactly as shown
