Cavity Maxi Fuse Mini Fuse Description
F17 20 Amp Yellow
ECM, Injectors (3.6 Gasoline
Engine)
F17 20 Amp Yellow
Secondary Loads, ECM
(3.0 Diesel Engine)
F18 7.5 Amp Brown
KL30 ECM, KL30 Main Relay
Coil (3.6 Gasoline Engine)
F18 7.5 Amp Brown
KL30 MTA, KL30 ECM,
KL30 Main Relay Coil (3.0
Diesel Engine)
F19 7.5 Amp Brown A/C Compressor (If Equipped)
F20 30 Amp Green Windshield Wiper
F21 15 Amp Blue Fuel Pump
F22 20 Amp Yellow
ECM, Ignition Coils (3.6 Gaso-
line Engine)
F22 20 Amp Yellow
ECM, Primary Loads (3.0 Die-
sel Engine)
F23 20 Amp Yellow ESC Valves
F24 7.5 Amp Brown
KL15 Vacuum pump relay coil
(3.6 Gasoline Engine) – If
Equipped
F30 15 Amp Blue Heated Mirrors
Front PDC Additional Fuses
The additional fuse box is located inside the front PDC Box.
Cavity Mini Fuse Description
F61 20 Amp Yellow
Vacuum Pump (3.6 Gasoline Engine) – If
Equipped
F62 30 Amp Green
Transmission Power RELE (3.6 Gasoline
Engine) – If Equipped
F64 7.5 Amp Brown
Urea Pump (3.0 Diesel Engine) – If
Equipped
F65 25 Amp Clear
Urea NOX Sensor 1–2 — PM Sensor
(3.0 Diesel Engine) – If Equipped
F66 5 Amp Beige STM (3.6 Gasoline Engine) – If Equipped
MAINTAINING YOUR VEHICLE
126
