Interior Fuses
The interior fuse panel is part of the Body Control Module (BCM) and is located on the
driver's side under the instrument panel.
Cavity Mini Fuse Description
F12 10 Amp Red Right Low Beam
F13 10 Amp Red Left Low Beam
F31 5 Amp Tan INT/A
F32 10 Amp Red SBMT
F34 7.5 Amp Brown Clearance Lights
F36 15 Amp Blue +30 (ACM – TPCU – RRM – DLC)
F37 5 Amp Tan INT (BRAKE NO – IPC)
F38 15 Amp Blue Central Locking
F42 5 Amp Tan INT (BSM – SAS – BRAKE NC)
F43 20 Amp Yellow Bi-Directional Washer Pump
F47 20 Amp Yellow Driver Power Window
F48 20 Amp Yellow Passenger Power Window
F49 5 Amp Tan INT (PAM – CCS – RRM – ECM)
F50 7.5 Amp Brown INT (ORC)
F51 5 Amp Tan INT (REAR CAMERA-AUX)
F53 5 Amp Tan +30 (IPC)
F90 7.5 Amp Brown Left High Beam
F91 7.5 Amp Brown Right High Beam
F92 7.5 Amp Brown Left Fog Lamp
F93 7.5 Amp Brown Right Fog Lamp
Right Central Pillar Fuses
The right central pillar fuse panel is located on the interior side at the base of the
passenger side B-Pillar.
Cavity Mini Fuse Description
F81 7.5 Amp Brown Seat Heater
F83 20 Amp Yellow Rear Left Windows Heater
F84 20 Amp Yellow Rear Right Windows Heater
F85 10 Amp Red Rear Heater Prep
MAINTAINING YOUR VEHICLE
127
