TRAKFAST REPAIR MANUAL
55
Rev. 09/07
TOOL REASSEMBLY
Housing Assembly - (cont’d)
Place Grill on Cap Assembly.
Slide in and tap down.
Place Shear Block into Nosepiece.
Slide Magazine onto Handle/Housing Assembly.
Secure Magazine Assembly and Housing together with Knob.
Place Battery in Tool.
Slide Carrier back into lock position.
Press down on Nosepiece. Motor will come on.
