TRAKFAST REPAIR MANUAL
57
Rev. 09/07
TOOL REASSEMBLY
Nosepiece Assembly — Telescoping Nose
Telescoping Nosepiece Assembly (part #801130A).
Check for any damage.
Nose and Flange should be tight and without movement.
Slide Lower Probe into Nosepiece.
Replace Probe if bent or grommet is worn or missing.
Place Guide Block in Nosepiece.
Secure with screws.
Check for damaged parts.
