TRAKFAST REPAIR MANUAL
58
Rev. 09/07
TOOL REASSEMBLY
Nosepiece Assembly — Telescoping Nose
Slide Lockout Probe onto Work Element.
Check for any damage.
If the Work Element is burred, the fasteners will not flow into the
firing position.
Slide Lockout Probe and Work Element onto the Nosepiece.
Place Stop Plate on Nosepiece.
Secure with screws.
Use Loctite #242 (Blue) on screw threads.
To Next Page
