Rangemaster Elise 100 Induction - 9 Technical Data

27
9. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below door opening.
COUNTRIES OF DESTINATION: GB, IE.
Connections
Electric 230 / 400 V 3N 50 Hz
Dimensions
Total height (to hotplate) Min 910 mm Max 935 mm
Total width 994 mm
Total depth 600 mm (to fascia); 650 mm (over handles)
Minimum height above cooker 650 mm
Refer to ‘Positioning the Cooker’.
Ratings
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.85 kW
Boost: 3.0 kW
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.15 kW
Boost: 2.0 kW
Max: 1.15 kW
Boost: 2.0 kW
Ovens
Main Oven Tall Oven
Multi-function Forced Air Convection
Maximum power output @ 230 V 50 Hz 2.5 kW 2.5 kW
Energy eciency class on a scale of A (more ecient) to G (less ecient) A A
Energy consumption based on standard load 0.95 kWh 0.99 kWh
Usable volume (litres) 69 81
Size Large Large
Time to cook standard load 41 minutes 48 minutes
Surface area of the grid 1400 cm
2
1056 cm
2
Grill 2.3 kW
Maximum total electric load at 230 V 50 Hz
(approximate total including oven lights, oven fan, etc.): 14.8 kW.
