9. Technical Data
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below the oven door opening.
COUNTRIES OF DESTINATION: GB, IE.
Connections
Electric 230 / 400 V 50 Hz
Dimensions
Elan Classic Deluxe Professional Deluxe
Overall height min 905 mm max 930 mm min 905 mm max 930 mm min 905 mm max 930 mm
Overall width 1100 mm 1100 mm 1100 mm
Overall depth
597 mm
(to fascia inc. splashback)
679 mm (over handles)
597 mm (to fascia inc. splashback)
666 mm (over towel rail)
595 mm (to fascia)
642 mm (over handles)
Minimum space above hotplate 650 mm 650 mm 650 mm
Toledo Classic Professional+
Overall height min 905 mm max 930 mm min 905 mm max 930 mm min 905 mm max 930 mm
Overall width 1100 mm 1100 mm 1100 mm
Overall depth
596 mm
(to fascia inc. splashback)
654 mm (over handles)
596 mm (to fascia inc. splashback)
657 mm (over towel rail)
596 mm (to fascia)
642 mm (over handles)
Minimum space above hotplate 650 mm 650 mm 650 mm
See “Positioning the Cooker“.
Ratings
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.85 kW
Boost: 3.0 kW
Max: 1.85 kW
Boost: 2.5 kW
Max: 1.15 kW
Boost: 2.0 kW
Max: 1.15 kW
Boost: 2.0 kW
DocNo.100-0003 - Technical data - IN 110 - GENERIC
