DST-64T / DST642D Wheel Balancers 37 P/N 5900192 — Rev. F — March 2021
Static Balancing (STA Mode)
Static Balancing is for Wheels under 4 inches wide and motorcycle Wheels.
Note: The Optimize Function is not available for Static Mode.
If the Wheel is out of balance, weight must be applied to the Center Plane when using Static Mode.
STA Mode
To Balance a Wheel using Static Mode:
Make sure you are dressed appropriately: leather gloves, steel-toed work boots, back belts,
hearing protection, and ANSI-approved eye protection: safety glasses, face shield, or goggles.
Visually inspect the Balancer to make sure everything is in place. The Hood should be
up
.
Make sure the Wheel you want to balance is both
clean
and
free of any weights
that may
have been put on previously.
Mount the Wheel on the Balancer.
Refer to Mounting a Wheel for mounting instructions, if needed.
Turn the Balancer Off and then back On, to reset it.
On power up, baL xx appears in the Inner and Outer Windows. The xx is a numeric value that
indicates the software version being used.
After a few seconds, default values appear in the Distance, Width, and Diameter Windows.
On the Control Panel, press the STA button until the STA (Static Mode) indicator is lit.
Pull out the Inner Arm and place it on the Center Plane of the Wheel and hold it there;
wait for
the Balancer to beep
.
When the Balancer beeps, return the Inner Arm to
its rest position.
Lower the Hood; the Wheel spins briefly.
Raise the Hood when the Wheel stops.
The Inner Window shows St and the STA mode
indicator is lit.
The Center Width Window shows the correction
weight you need to add to the Center Plane.
Turn the Wheel slowly to find the best location to
apply the weight, both Inner and Outer position
indicators are all lit.
When the Wheel is in the right location, all the Inner
and Outer Plane Wheel Positions light.
Hold the wheel in place at this position with the
Brake. Add the correct amount of weight at 12 o’clock Top Dead Center.
