Cooling System Capacity: 6.8 litres (12 Imp. pints)
(14.4 US pints)
Fuel Tank Capacity: 60 litres (13.2 Imp. galls)
(13.7 US galls)
Hydraulic Tank Capacity: 52 litres (11.4 Imp. galls)
(15.8 US galls)
DIMENSIONS (Fig.2)
Width of cut: 3.50 meters (138in)
Overall width:
(transport)(A) 2.00 metres (78.8in) min.
Overall height:(B) 1.45 metres (57in)
Overall length:(C) 3.10 metres (123in)
Uncut turning circle: 1.30 metres (51in)
Ground Clearance:
Sport 200 198mm (7 3/4in)
Magna 250 161mm (6 5/16in)
Wheel base:(D) 1.65 metres (65in)
Wheel track - front:(E) 1.50 metres (59in)
Wheel track - rear:(F) 1.22 metres (48in)
Overall weight of machine:
with Magna 250 6-knife fixed head units 1980kg
(4363lb)
NOISE EMISSION
Conforms to the specification of Directive
EEC 79/113, 84/538, 87/252, 88/180, 88/181
Sound Power Level: 104 dB(A) LWA (Bystander)
Sound Pressure Level: 89.4dB(A) LpA (Operator
Ear Level)
VIBRATION LEVEL
The machine was tested for whole body and hand/
arm vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and
the cutting device was rotating with the machine
stationary.
Hand / Arm acceleration level : 1.45 m/s
2
Whole body acceleration level
X axis : 0.27 m/s
2
Y axis : 0.59 m/s
2
Z axis : 0.19 m/s
2
RECOMMENDED LUBRICANTS
Engine oil: Should be to MIL-L-2104C or to A.P.I.
Classification CC/CD/CE grades and
as given in the table below:
Temperature Oil Viscosity
ABOVE 25°C (77°F) SAE 30 or SAE 10W-30
0°C to 25°C (32°F to 77°F) SAE 20 or SAE 10W-30
BELOW 0°C (32°F) SAE 10W or SAE 10W-30
Hydraulic Oil: To ISO.VG.46. Shell Tellus 46
or equivalent.
Grease: Shell Darina R2 or equivalent.
