Ransomes Commander 3510 - SOLENOID CONTROL CIRCUIT

GB-NL-F-81
SOLENOID CONTROL
CIRCUIT
Fig.52
1. Cutter circuit foot switch
2. Cutter circuit solenoid
3. Diff lock foot switch
4. Four wheel drive solenoid
5. Differential lock solenoid
6. 4 Wheel Drive switch
18. Earth
GB
F3 Fuse
F4 Fuse
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
Note:
Circuit connectors are indicated on the diagram
by a letter ' A', 'B', followed by a number
