GB-NL-F-40
GB
FITTING DEFLECTORS TO CUTTING UNIT
a. Assemble two bolts and two spacers into each
deflector.
b. Fit deflector between cutting unit side plates,
align the flats on the bolts with the flats in the
mounting holes.
c. Push the bolts through the side plates with a
suitable rod.
d. Secure with stiffnuts, tighten until deflector
becomes stiff to move.
CENTRE UNIT STOPS(Floating Head Sport 200)
a. Remove the rubber stops from under the
chassis and retain the rubber stops and screws.
b. Refit rubber stops with extensions to the
chassis, secure with retained screws.
