GB-F-NL-33
GB
RANSOMES T-PLEX 180
OPERATORS MANUAL
CUTTING PERFORMANCE
The cuts per metre (cuts per yard) are dependant upon the forward speed of the machine.
39 cuts per meter at 6.4 km/hr (5 Knife fixed head.) 83 cuts per metre at 6.4 km/hr (7 Knife floating head.)
36 cuts per yard at 4mph (5 Knife fixed head.) 76 cuts per yard at 4 mph (7 Knife floating head.)
CUTTING PERFORMANCE (AREA)
0.9 hectares/hr. at 6.4 km/hr. (2 acres/hr. at 4 m.p.h.)
Allowance is included for normal overlaps and turning at the end of each cut.
FIXED HEAD UNIT HEIGHT OF CUT CHART
POSITION
1 2 3 4 5 6 7 8 9
mm in. mm in. mm in. mm in. mm in. mm in. mm in. mm in. mm in.
13 0.5 19 0.75 25 1 31 1.25 38 1.5 44 1.75 50 2 56 2.25 63 2.50
FLOATING HEAD UNIT HEIGHT OF CUT CHART
POSITION
1 2 3 4 5 6 7
mm in. mm in. mm in. mm in. mm in. mm in. mm in.
6 0.25 13 0.5 19 0.75 25 1.00 31 1.25 38 1.5 44 1.75
