Ransomes T-Plex 180 - Page 65

GB
63
T-PLEX 180
OPERATORS MANUAL
ELECTRICAL CIRCUIT
ENGINE AND SAFETY
KEY TO WIRING DIAGRAM (Fig.36)
1. Battery
2. Starter motor
3. Generator
4. Regulator
5. Earth
6. Start solenoid
7. Fan
8. Ammeter
9. Hourmeter
10. Key switch
11. Seat switch timer
12. Seat switch
13. Fuse (20 amp)
14. Fuse (10 amp)
15. Optional 3WD switch
16. Neutral microswitch
17. Cylinder microswitch
18. Fuse (15 amp)
19. Engine kill wire
20. Optional fuel solenoid
21. Relay 1
22. Relay 2
23. Diode 1
24. Diode 2
25. Oil pressure switch
26. Fan Relay
27. Thermo-switch
Key switch positions
28. Off
29. Run
30. Start
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
BG Black Green
BO Black Orange
NU Brown Blue
WG White Green
WY White Yellow
