Rapid Engineering BH-40 - Burner Tube Installation

BH-SERIES INSTALLATION, OPERATION AND SERVICE MANUAL
18 of 59
FIGURE 17: Linear Heater Layout Overview (Continued)
Step 6.1 Burner Tube Installation
g
c
b
de
f
e e e e
g
c
b
de
f
e e e e e
g
c
b
de
f
e e e e e e
60' (18.3 m) Tube Length
70
' (21. 3 m) Tube Length
80
' (24.4 m) Tube Length
7' 6" ± 1'
(229 cm ± 25 cm)
NOTE:
Tubing requires a downward
slope of 1/2" (13 mm)
per 20
' (6 m) away
from burner.
S-Hook
Burner Tube
Hanger
Offset mounting
hole must be
to the top.
Weld seam
must be to the
bottom of the tube.
Description Part Number
Burner Tube 03051XXX
S-Hook 91907302
Tube/Reflector Hanger 03090100
