SECTION 7: OPTIONAL HEATER ACCESSORIES
33 of 59
Step 7.5.2 Frame Shield Installation
Step 7.5.3 Reflector Side Extension Installation for Decorative Grilles
Description Part Number
Deco Grille Shield 01365900
Description Part Number
Reflector Side Extension 01370412
Distance "A" Extension
Minimum Maximum Part No. Width
2" (4 cm) 6" (15 cm) 01370408 8" (20 cm)
6" (15 cm) 10" (26 cm) 01370412 12" (30 cm)
10" (26 cm) 14" (37 cm) 01370416 16" (40 cm)
