Rapido F110 NT - Dimensions; Technical Data

Dimensions
6. Technical data
13
Measurements
in mm
F 110/3
NT
F 110/4+4.1
NT
F 110/5+5.1
NT
F 110/6+6.1
NT
Measurements
in mm
F 110/3
NT
F 110/4+4.1
NT
F 110/5+5.1
NT
F 110/6+6.1
NT
H 910 910 900 900 H 4 517 517 507 507
H 1 760 760 750 750 H 5 75 75 65 65
H 2 305 305 295 295 T 465 595 725 855
H 3 665 665 655 655 D 1 130 130 150 150
thickness of burner door 95 95 95 95
Fig. 3
front view
side view from left rear view
cleaning lid
Type F110/3 NT F110/4 NT F110/4.1NT F110/5NT F110/5.1NT F110/6NT F110/6.1NT
Nominal heating capacity kW 16,0-24,0 24,0-32,0 32,0-40,0 40,0-48,0 48,0-56,0 56,0-64,0 64,0-70,0
Nominal heating load kW 17,5-26,5 26,1-34,9 34,5-43,9 43,7-52,1 51,9-61,5 60,9-69,6 68,9-76,4
Combustion chamber depth mm 265 395 395 525 525 655 655
Heat gas resistance mbar 0,10 0,12 0,14 0,16 0,18 0,20 0,23
Draught pressure mbar 0,10 0,12 0,14 0,16 0,18 0,20 0,23
Boiler gas capacity m
3
0,030 0,044 0,044 0,058 0,058 0,072 0,072
Water resistance
when
T = 10 K mbar
when
T = 20 K mbar
2,85
0,713
5,04
1,260
7,91
1,989
11,3
2,840
15,5
3,875
20,2
5,050
25,65
6,412
Permitted total excess pressure bar
6 6 6 6 6 6 6
Max. adjustable advance pressure °C 85 85 85 85 85 85 85
Electrical connection V/Hz 230/50 230/50 230/50 230/50 230/50 230/50 230/50
Weight kg 138 173 176 212 217 249 255
Water capacity l 19 26 26 33 33 40 40
Flue gas flow mass** g/s 7,5-11,1 11,1-14,7 14,7-18,6 18,6-22,2 21,9-26,1 25,8-29,4 29,2-33,6
Heating surface m
2
0,950 1,443 1,443 1,935 1,935 2,427 2,427
Standby loss %
tv 80°C
tv 40°C
0,9
0,3
0,7
0,3
0,7
0,3
0,5
0,2
0,5
0,2
0,27
0,1
0,27
0,1
Gross flue temperature* with 13 % CO
2
°C 160-198 160-188 160-193 160-180 160-195 160-176 160-191
Number of radiation converters 4 2 (middle) 4 2 (middle) 4 2 (middle) 4
Flue baffle plate 1 - 1 - - - -
Re-circulation pipe 130x140 140x177 140x177 140x177 140x177 - -
Water distribution pipe - 1 1 1 1 1 1
Advance connection Rp 1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
Back-flow connection Rp 1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
1
1
4
CE-product-ID-number CE-
0085AQ1190
CE-
0085AQ1190
CE-
0085AQ1190
CE-
0085AQ1190
CE-
0085AQ1190
CE-
0085AQ1190
CE-
0085AQ1190
*Flue temperature is indicative only. Varying types of fabrication and dirt on heating surfaces can both lead to different values.
**Calculated on basis of chimney construction according to DIN 4705, building type-approval identification mark 08-266-342-x DIN
registration No. (DIN 4702) K 2066/87. We recommend the use of a burner with oil pre-heating with the F 110/3 NT.
