Raritan PM Series - DIN Rail Mounting PMM + PMB

Power Meter Quick Setup Guid
e
8
QSG
-PMM-1A-v3.3.10-E  255-64-0004-00
DIN Rail Mounting PMM + PMB
BOTTOM
A
Expansion Connector
supplied with PMB.
Do not hot-plug the
Expansion Port! PMM and
PMB must be
disconnected from all
power source before
plugging Expansion Port.
Snap Expansion Connector
to Expansion Ports on
bottoms of PMM and PMB.
TOP
B
35mm DIN rail
C
PMM
D
PMB
E
Modules snap into rail. Pull
white tab here to remove.
