Rascal AutoGo - Dash Release and Frame Lock

Rascal AutoGo Owner’s Manual
EMC Part: 19286400 Rev.01 03/09/07
25
2. Pull Dash Release up and lift dash to upright position to engage wheel locks onto front wheels, see Illustration 7.
Illustration 7 — Dash Release Lever
3. Position yourself on the right side of the Rascal AutoGo. Press the foot lever, as shown in Illustration 8, to retract the
frame lock.
Illustration 8 — Foot Release & Frame Lock
