Rascal AutoGo - Unfolding Flat Folded Vehicle

Rascal AutoGo Owner’s Manual
EMC Part: 19286400 Rev.01 03/09/07
30
To unfold the Rascal AutoGo after being folded flat:
• Raise tiller and dash to upright position
• Pull dash release lever and return dash to driving
position
• Raise seat frame and lock into position using the Seat
Frame Cams
• Re-install seat (if removed)
Unfolding is shown in Illustration 11. Make sure to test
before riding.
Illustration 11 — Unfolding Flat Folded Vehicle
