49
Compass
To navigate the menu follow the instructions in the picture on the left
Compass resolution: 1°
Compass accuracy: +/-1°
Do you know what?:
The RATIO iX3M is provided with the most innovative compass. Check always a compass’ resolution and
accuracy before entrusting it your route .
Press D
Button to memorise the current Route
When in “Compass” mode the iX3M shows::
DIRECTION (on the top centre): the current direction expressed in
degrees (°)
GRAPHIC COMPASS (on the centre): graphic compass with route
indications.
Direction in route (+/- 5° in comparison with the one set with D)
It indicates the direction to follow to find the route you have set
Reciprocal direction (+/- 5° in comparison with the set reciprocal route )
DIR: Current set route
REC: Reciprocal of the set route
Do you know what?:
The RATIO iX3M’s 3D compass is compensated by 2 accelerometres. The iX3M can compensate your arm’s grade
automatically up to an angle of 85° from the horizontal position.
ATTENTION:
The Compass works correctly
only if its calibration has been
done correctly.
See paragraph: COMPASS
To reach this menu from the main
screen press in sequence:
0°
0°
180°
DIR
REC
N
E
W
. .
.
. . .
.
NE
NW
.
A C
C
D
ExIT
APP
MENU
ROUTE
