Logbook
To navigate the menu follow the instructions in the picture on the left.
The fi rst visualized dive is the most recent one.
Do you know what?: The dive diagram shown in the RATIO iX3M’s Logbook is in HD and exploits at
maximum the device screen’s defi nition.
N: Dive’s number, beginning time and date.
RT: RunTime (dive’s duration)
MAX: Maximum reached depth
CNS: Accumulated CNS %
OTU: Accumulated OTU
BUL(/VPM): Selected algorithm and conservativism factor
MIX: Main used mix (bottom mix)
MODE: Dive mode (OC= Open Circuit, CC=Rebreather)
TEMP: Minimum recorded temperature
B
To reach this menu from the main
screen press in sequence
LOGBOOK
RT:
MAX:
CNS:
OTU:
BUL:
MIX:
MODE:
TEMP:
39:
41.1m
5%
15
93/93
21/0
OC
+18°C
54 12:10 11.06.15
N
B
A C D
EXIT
EXIT <=
=>
A
C
