Rational iCombi Classic

4 | Transport
26 / 108 80.06.070_iCombiPro-iCombiClassic_IM_en-GB
2. Insert the four lifting lugs into the slots on the sides of the unit (1) with the
top side upwards.
3. Feed in the lug diagonally (2) and turn it clockwise 90° (3).
90°
2
3
> The lug can no longer be pulled out (4).
> The top side of the lifting lugs is marked with TOP.
4
4. Attach the bar to the lifting lugs.
> Use the short bars for units sizes 6-1/1 and 10-1/1.
> Use the long bars for units sizes 6-2/1 and 10-2/1.
