Raven RS1/HDU Installation Manual

Chapter6
Install the SC1™/TC1™ Unit
NOTICE
Depending upon the make and model of the machine, the steps
required to complete the installation of the RS1™/SC1™ with
DirecSteer auto-steer system may differ from the instructions
provided in the following procedure.
Note: Contact an authorized dealer for assistance with ordering or installing the SC1™
mounting kit for a specific machine.
1. Install the SC1™ on the mounting bracket (P/N107-8000-125/157) using the supplied
screws from the Node Seat Mount Bracket Kit (P/N117-8000-255).
2. Locate the desired installation position next to the seat.
3. Remove the two flange bolts on the right side of the seat.
56
