Manual No. 016-5033-151 Rev C. EC30597 12/17 13
TERRAGATOR B RAVEN RS1™ ISO GUIDANCE AND STEERING INSTALLATION GUIDE
12. Connect the WAS Adapter Cable (P/N 115-4010-054) between the machine’s WAS harness and the sensor.
NOTE: When performing the initial RS1 WAS calibration, verify that the voltage reported by the sensor
changes value all the way to both the left and right locks.
OPERATION
Refer to the RS1 Calibration and Operation Manual (P/N 016-4010-001) for instructions on configuring, calibrating,
and operating RS1. Please note the location of the master switch and the resume button on the machine since they
are needed for operation.
FIGURE 24. Master Switch and Foot Pedal
Master Switch
Resume Button
To Next Page
