CHAPTER 2
10 Miller Nitro 5000 Series & New Holland Guardian F Series RS1™ HDU Guidance and Steering Installation Manual
Bolt - 3/8”-16 x 3” Hex 311-0054-113 1
Bolt - M6 1.0 x 20 mm Class 5.8-8.8 Flanged Lock 311-0070-051 3
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-164 1
Nut - 1/4”-20 UNC Flanged Lock 312-1001-168 2
Nut - #6-32 Zinc Nylon Insert Lock 312-4000-052 2
Washer - 5/16” Lock 313-1000-019 4
Washer - 0.344” ID x 0.688” OD x 0.065” Thick 313-2300-312 4
TABLE 2.
Hydraulic Kit (P/N 117-0199-124)
Item Description Part Number Qty.
Fitting - -8 ORFS M/M/F Swivel Run Tee Adapter 333-0012-028 4
Fitting - -4 SAE O-Ring Hex Plug 333-0012-051 1
Fitting - -6 ORFS (M) to -6 SAE O-Ring (M) Adapter 333-0012-084 2
Fitting - -4 ORFS (M) to -6 SAE O-Ring (M) Straight Adapter 333-0012-195 1
Fitting - -6 ORFS (M) to -8 SAE O-Ring (M) Straight Adapter 333-0012-199 2
Fitting - -6 ORFS (M) to -10 SAE O-Ring (M) Straight Adapter 333-0012-233 2
TABLE 1.
RS1 HD Installation Kit (P/N 117-5032-114)
Item Description Part Number Qty.
