Chapter 5
36 SCS 660 & 660M Serial Interface for Granular Applications Installation & Service Manual
Rate 1 Change Request = $R, RC, <rate_1_cal> <CR> <LF>
Calibration String Values Request = $R, CR <CR> <LF>
Data String Request = $R, DR <CR> <LF>
SCS 660 Console to Remote Computer Data Strings
All request strings begin with $R, indicating a Raven communication string. In the example below, the 126
value indicates the last three digits of the programmed chip part number in the console, and C is the software
revision letter of the console.
Calibration strings = $R126C, C1, <switch_byte_1>, <switch_byte_2>, <boom_1_cal>,
<boom_2_cal>, <boom_3_cal>, <boom_4_cal>, <boom_5_cal>,
<boom_6_cal>, <speed_cal> <CR> <LF>
= $R126C, C2, <meter_cal>, <CR> <LF>
= $R126C, C3, <valve_cal>, <rate_1_cal>, <rate_2_cal> <CR> <LF>
Data Strings = $R126C, D1, <total_area>, <field_area> <CR> <LF>
= $R126C, D2, <total_volume>, <field_volume> <CR> <LF>
= $R126C, D3, <tank_volume>, <distance> <CR> <LF>
Actual Rate = $R126C, AR <actual_rate> <CR> <LF>
Time/Date = $R126C, TD, <hr:min>, <month/day/year>, <field_reference> <CR> <LF>
Self Test Feature
The self test feature simulates speed so that the system may be tested without moving. The self test feature
will clear itself when vehicular motion is detected by the speed sensor. A speed cal value of 900 [230] or
greater is recommended when operating in this mode.
Note: To prevent the self-test speed from clearing itself out automatically, disconnect the speed
connector on the back of the console when radar or Phoenix 10 speed sensors are used.
1. Press the SELF TEST button.
Bit Switch Byte 1 Switch Byte 2
0boom 1 0
1boom 2 0
2boom 3 0
3 boom 4 rate 1
4 boom 5 rate 2
5boom 6 0
60 0
71 1
Note: If rate 1 and rate 2 are both zero, the console is in
Manual mode. For switch bytes, 0 = off and 1 = on.
